Mann — Whitney U-test

Probability and Statistics

Ihor Miroshnychenko

Kyiv School of Economics

Basic concepts

This time, let’s invent a new homogeneity criterion that tests the bias of one sample relative to another.

Recall the null hypothesis of the homogeneity test:

\[ H_0: F = G,\ vs. H_1: F \neq G \]

where \(F\), \(G\) are distribution functions of 2 samples.

Previously, we have relied on the values of the sample items; this time, it is suggested to look not at the values themselves but at their order relative to each other.

Mann — Whitney U-test

Idea: Let’s count the number of pairs where the orange element is larger than the blue element; if there are many or few such pairs, then one sample will be biased relative to the other.

\[ \begin{align} U = \sum_{i}^N\sum_{j}^M I[A_i < B_j] \end{align} \]

where \(A_1, ..., A_N\) — the first sample, \(B_1, ..., B_M\) — the second sample, \(I\) — an indicator function which is 1 if the condition in parentheses is met, and 0 otherwise.

Count the number of pairs

If \(H_0\) is true, then the number of pairs where \(A_i < B_j\) should be close to \(n \times m / 2\).

  • \(n\) = 50
  • \(m\) = 50

So the expected value of \(U\) is \(50 \times 50 / 2 = 1250\).

But in our case, \(U\) = 2205.

We need to figure out if 2205 is a lot or a little.

U-distribution for case

Quantile: 955.925 - 1532.05

\(U\) = 2205 is in the tail of the distribution, which means that the null hypothesis is rejected.

But this will work only for this case. We need a more general approach.

Mann — Whitney U-test

\[ \begin{align} &U \overset{H_0}\rightarrow \mathcal{N}(\mathbb{E}U, \mathbb{D}U), \text{where}\\ &U = \sum_{i}^N\sum_{j}^M I[A_i < B_j],\\ &\mathbb{E} U = \dfrac{NM}{2},\\ &\mathbb{D}U = \dfrac{NM(N + M + 1)}{12} \end{align} \]

The minus of our current solution is that it takes a long time to run, specifically in quadratic time.

Speeding up the calculation: ranks

Idea on how to speed up the criterion: let’s organize all the elements in the graph below—the leftmost element — first, the next — second, etc. Let’s call these numbers ranks.

\(A = \color{#181485}{[1, 5, 8, 20]}\)

\(B = \color{#FFA500}{[2, 3, 6]}\)

\(A \& B = [\color{#181485}1, \color{#FFA500}2, \color{#FFA500}3, \color{#181485}5, \color{#FFA500}6, \color{#181485}8, \color{#181485}20]\)


\(R_j\) is the rank of \(B_j\) in the sample \((A_1,\ ...,\ A_N,\ B_1,\ ...,\ B_M)\).

\(V = R_1 +\ ...\ ...\ + R_M\).

Idea \(V\): the more biased one sample is relative to another, the greater/smaller the sum of ranks of one sample.

\[U = V - \dfrac{M (M + 1)}{2}\]

Algorithm of the Mann — Whitney U-test

Hypothesis to be tested: \(H_0: F=G,\ vs.\ H_1: F \neq G\).

  • The sample ranks \(A_1,\ ...\ A_N,\ B_1,\ ...\ B_M\) are calculated.

  • All ranks of sample \(B\) are saved: this is sample \(R\).

  • The sum of the ranks of sample \(B\) in the list \(A \& B\) is taken: \(V = R_1 +\ ...\ ...\ + R_M\). The statistic \(U = V - \dfrac{M (M + 1)}{2}\) is calculated

  • The expected value and variance under \(H_0\), are calculated: \[ \begin{align} &\mathbb{E} U = \dfrac{NM}{2},\\ &\mathbb{D} U = \dfrac{NM(N + M + 1)}{12} \end{align} \]

  • \(U \overset{H_0}\rightarrow \mathcal{N}(\mathbb{E}U, \mathbb{D}U)\). Quantiles are calculated from this distribution.


It does not depend on noise in the data!
