Ratio-metrics and Linearization

Applied Statistics

Ihor Miroshnychenko

Kyiv School of Economics

Independent and dependent samples

Task

You are an analyst at OLX. Recently, a product manager approached you and requested to change the color of the “write a message” button in ads from blue to red.

Question

Will this increase the conversion rate for button clicks?

Data

Conversion rate is defined as the ratio of the number of users who started a chat conversation to the number of users who visited the ad page.

Conversion Rate Data
User ID Visits the ad page Start a chat conversation
1 5 5
2 4 1
3 0 0
4 6 4
Total 15 10

\[ \begin{align*} \text{Conversion Rate} &= \frac{\text{Number of Conversations}}{\text{Number of Visits}} \\ &= \frac{10}{15} = \frac{2}{3} \approx 0.67 \end{align*} \]

Split the data

For example: users 1 and 3 will be in the control group, and users 2 and 4 will be in the test group.

Conversion Rate Data
User ID Visits the ad page Start a chat conversation
1 5 5
2 4 1
3 0 0
4 6 4
Total 15 10

Which test to use?

T-test: visits to the ad page

ABTest cluster_test Test cluster_control Control T2 user 2 T2a 0 T2->T2a T2b 0 T2a->T2b T2c 0 T2b->T2c T2d 1 T2c->T2d T4 user 4 T4a 0 T4->T4a T4b 1 T4a->T4b T4c 1 T4b->T4c T4d 1 T4c->T4d T4e 1 T4d->T4e T4f 1 T4e->T4f K1 user 1 K1a 1 K1->K1a K1b 1 K1a->K1b K1c 1 K1b->K1c K1d 1 K1c->K1d K1e 1 K1d->K1e K3 user 3 K3a K3->K3a

Let’s:

  • \(M_O^C,\ M_O^T\) are random variables in the test and control groups, equal to 1 or 0.
  • \(O\) at the bottom means that the statistical unit of measurement is the number of announcements opened by the user.
  • \(M\) means whether correspondence has begun in the messenger.

T-test: visits to the ad page

Hypothesis:

\[ H_0: \mathbb{E}\overline{M_O^C} = \mathbb{E} \overline{M_O^T}\ VS.\ H_1: \mathbb{E}\overline{M_O^C} < \mathbb{E} \overline{M_O^T} \]

Can we use the t-test here?

What if the entire difference between the groups is due to different users rather than the effect between the test and control groups?

For example, the first user does not like to call and always writes in the chat, while the others do not.

T-test: visits to the ad page

Monte Carlo simulation:

  • Function to generate artificial user \(i\)
    • In the first stage, we generate the number of ads the user clicked on the website. Let this number be \(O_i\), which we generate from a normal distribution for simplicity.
    • In the second stage, we generate the conversion \(p_i\) of clicking on the “write message” button.
    • Thus, for each user, we will obtain a sample of size \(O_i\) with conversion \(p_i\). To speed up the process, we will assume that the number of chats will be exactly \([O_i \cdot p_i]\) (the integer part of \(O_i \cdot p_i\)).
  • In this case, users will be taken from a single distribution: there will be no difference between users in the test and control groups.

T-test: visits to the ad page

  1. O_array: number of visits to the ad page by each user in the group, generated from a normal distribution.
  2. p_array: conversion rate for each user, generated from a uniform distribution.
  3. sample_size: total number of visits to the ad page in the group.
  4. M_sum: total number of chats started in the group, calculated as the sum of the products of O_array and p_array.
  5. Return a sample consisting of M_sum ones (chats started) and the rest zeros (no chats started).
  • \(N = 1000\): number of simulations
  • \(\alpha = 0.05\): significance level
  • \(n = 1000\): number of visits to the ad page in each group
Code
def generate_incorrect_group_sample(group_size, p=0.3):

    O_array = norm(loc=10, scale=1).rvs(size=group_size).astype(int)
    p_array = uniform().rvs(size=group_size)

    sample_size = numpy.sum(O_array)
    M_sum = numpy.sum((O_array * p_array).astype(int))

    return [1] * M_sum + [0] * (sample_size - M_sum)


numpy.random.seed(42)
mc_size = 1000
bad_cnt = 0
alpha = 0.05
group_size = 1000

for _ in range(mc_size):
    test_sample = generate_incorrect_group_sample(group_size)
    control_sample = generate_incorrect_group_sample(group_size)

    pvalue = ttest_ind(test_sample, control_sample, equal_var=True, alternative='two-sided').pvalue

    bad_cnt += (pvalue <= alpha)

print(f"FPR: {round(bad_cnt / mc_size, 4)}")
print(f"CI={proportion_confint(count = bad_cnt, nobs = mc_size, alpha=0.05, method='wilson')}")
FPR: 0.263
CI=(0.23665685979107837, 0.2911570237310747)

Why?

The t-test assumes that the data is independent and identically distributed (i.i.d.), which is not true in this case.

T-test: visits to the ad page

  • One user was in the test, and one was in the control, each of whom clicked on the ad 10,000 times.
  • The first user’s conversion rate for writing in the chat is 1, and the second’s is 0, always. One is afraid of phone calls, and the other loves to talk on the phone, so they will never write in the chat.
  • Then we will have a conversion of 1 in the test and 0 in the control.
  • The t-test will reject everything: it will have two samples of size 10,000: one of ones, the other of zeros.
  • If we swapped the users, the opposite would happen: the control would be better than the test.

The problem is that we only have two users, and the t-test is not applicable. So we “multiplied” them and obtained samples of size 10,000, and we are applying the t-test.

Baseline. T-test: users

Not conversion from opening an ad to chat, but an increase in chats!

Hypothesis:

\[ H_1: \mathbb{E}\overline{M^C} < \mathbb{E} \overline{M^T} \]

\(M^C,\ M^T\) — average number of visits to the messenger by users in the test and control groups.

In this case, we look at the average user rather than the open advertisement, as in the previous case.

We also eliminate dependencies in selections: opening a chat by one user does not affect the opening of a chat by another user.

Baseline. Monte Carlo simulation

  1. O_array: number of visits to the ad page by each user in the group, generated from a normal distribution.
  2. p_array: conversion rate for each user, generated from a uniform distribution.
  3. M_array: number of chats started by each user, calculated as the product of O_array and p_array.
  4. Return a sample consisting of M_array.
Code
def generate_group_sample(group_size):

    O_array = norm(loc=50, scale=5).rvs(size=group_size).astype(int)
    p_array = uniform().rvs(size=group_size)

    M_array = (O_array * p_array).astype(int)

    return {
        "O_array": O_array,
        "message_array": M_array
    }


numpy.random.seed(42)
mc_size = 1000
bad_cnt = 0
alpha = 0.05
group_size = 1000

for _ in range(mc_size):
    test_sample = generate_group_sample(group_size)
    control_sample = generate_group_sample(group_size)

    pvalue = ttest_ind(test_sample['message_array'], control_sample['message_array'],
                       equal_var=False, alternative='two-sided').pvalue
    bad_cnt += (pvalue <= alpha)

print(f"FPR: {round(bad_cnt / mc_size, 4)}")
print(f"CI={proportion_confint(count = bad_cnt, nobs = mc_size, alpha=0.05, method='wilson')}")
FPR: 0.05
CI=(0.03813026239274881, 0.06531382024425081)

Sensitivity enhancement

Question

What is the maximum number of chats any OLX user can have?

It’s unclear. But what if you know he only visited the page with one ad? Then you can easily answer the question: 1 chat.

This means the number of chats may strongly correlate with user ad visits.

And we don’t want to lose this information: if we can use it, we can create a more powerful criterion!

Hypothesis

Let:

  • \(O^C,\ O^T\) — the number of user ad views in the control and test groups.
  • \(M^C,\ M^T\) — the number of visits to the messenger by users in the test and control groups.

\[ \begin{align} &H_0: \mathbb{E} \dfrac{\sum M^T}{\sum O^T} - \mathbb{E} \dfrac{\sum M^C}{\sum O^C} = 0\ vs.\ \\ &H_1: \mathbb{E} \dfrac{\sum M^T}{\sum O^T} - \mathbb{E} \dfrac{\sum M^C}{\sum O^C} > 0 \end{align} \]

Confidence interval

Ultimately, we are interested in calculating the statistics

\[ K = \dfrac{\sum M_T}{\sum O_T} - \dfrac{\sum M_C}{\sum O_C} \]

and constructing a confidence interval for it. But how?


Bootstrap!

Bootstrap

In this case, it is essential to remember that in Bootstrap, you need to sample both the number of chats and the number of visits to the ad simultaneously, because they depend on a single user!

  1. Sample the number of chats and the number of visits to the ad page in the test and control groups.
  2. Calculate the statistic \(K\) for the sample.
  3. Repeat steps 1-2 many times (e.g., 10000 times).
Code
def ratio_bootstrap(message_array, message_control, n_test, n_control, alpha=0.05):
    theta_func = lambda MT, MC, OT, OC: numpy.sum(MT, axis=1) / numpy.sum(OT, axis=1) - numpy.sum(MC, axis=1) / numpy.sum(OC, axis=1)


    B = 1000
    batch_size = B // 20


    theta_asterisk_array = []

    test_size = len(message_array)
    control_size = len(message_control)

    test_inds_array = numpy.arange(0, test_size)
    control_inds_array = numpy.arange(0, control_size)
    for _ in range(0, B, batch_size):

        boot_t_inds = numpy.random.choice(test_inds_array, replace=True, size=(batch_size, test_size))
        boot_c_inds = numpy.random.choice(control_inds_array, replace=True, size=(batch_size, control_size))

        # Wrong way to sample with replacement
        # boot_MT = numpy.random.choice(message_array, replace=True, size=(batch_size, test_size))
        # boot_MC = numpy.random.choice(message_control, replace=True, size=(batch_size, control_size))
        # boot_OT = numpy.random.choice(n_test, replace=True, size=(batch_size, test_size))
        # boot_OC = numpy.random.choice(n_control, replace=True, size=(batch_size, control_size))
        boot_MT = message_array[boot_t_inds]
        boot_MC = message_control[boot_c_inds]
        boot_OT = n_test[boot_t_inds]
        boot_OC = n_control[boot_c_inds]

        theta_asterisk = theta_func(
            boot_MT, boot_MC, boot_OT, boot_OC
        ).ravel()
        assert len(theta_asterisk) == batch_size
        theta_asterisk_array = numpy.concatenate([theta_asterisk_array, theta_asterisk])
    left_theta_asterisk, right_theta_asterisk = numpy.quantile(theta_asterisk_array, [alpha / 2, 1 - alpha / 2])


    percentile_left_bound, percentile_right_bound = left_theta_asterisk, right_theta_asterisk
    return percentile_left_bound, percentile_right_bound


numpy.random.seed(8)

bad_cnt_correct_bootstrap = 0

for _ in range(mc_size):
    test_sample = generate_group_sample(group_size)
    control_sample = generate_group_sample(group_size)


    left_bound_correct, right_bound_correct = ratio_bootstrap(
        test_sample['message_array'],
        control_sample['message_array'],
        test_sample['O_array'],
        control_sample['O_array']
    )

    bad_cnt_correct_bootstrap += ((left_bound_correct > 0) | (right_bound_correct < 0))

corr_fpr = round(bad_cnt_correct_bootstrap / mc_size, 4)
corr_left, corr_right = proportion_confint(count = bad_cnt_correct_bootstrap,
                                           nobs = mc_size, alpha=0.05, method='wilson')
print(f"FPR, correct bootstrap: {round(corr_fpr, 4)},"\
      f" [{round(corr_left, 4)}, {round(corr_right, 4)}]")
FPR, correct bootstrap: 0.054, [0.0416, 0.0698]

t-test vs ratio-metrics power

To generate an AB test, we will slightly modify the user sample generation function: we will add the ability to change conversions in the test and control.

Code
def generate_group_sample_equal_cr(group_size, p=0.1):

    O_array = norm(loc=50, scale=5).rvs(size=group_size).astype(int)

    p_array = norm(loc=p, scale=p / 10).rvs(group_size)
    p_array = numpy.maximum(p_array, 0)

    M_array = (O_array * p_array).astype(int)

    return {
        "O_array": O_array,
        "message_array": M_array
    }

numpy.random.seed(8)

power_ratio_cnt = 0
power_means_cnt = 0

for _ in range(mc_size):
    test_sample = generate_group_sample_equal_cr(group_size, p=0.101)
    control_sample = generate_group_sample_equal_cr(group_size, p=0.1)

    left_bound_ratio, right_bound_ratio = ratio_bootstrap(
        test_sample['message_array'],
        control_sample['message_array'],
        test_sample['O_array'],
        control_sample['O_array']
    )

    pvalue_means = ttest_ind(test_sample['message_array'], control_sample['message_array'],
                       equal_var=False, alternative='two-sided').pvalue


    power_ratio_cnt += (left_bound_ratio > 0)
    power_means_cnt += (pvalue_means < 0.05)


power_ratio = round(power_ratio_cnt / mc_size, 4)
ratio_left, ratio_right = proportion_confint(
    count = power_ratio_cnt, nobs = mc_size, alpha=0.05, method='wilson')
print(f"power, ratio: {round(power_ratio, 4)},"\
      f" [{round(ratio_left, 4)}, {round(ratio_right, 4)}]")


power_means = round(power_means_cnt / mc_size, 4)
means_left, means_right = proportion_confint(count = power_means_cnt,
                                           nobs = mc_size, alpha=0.05, method='wilson')
print(f"power, means: {round(power_means, 4)},"\
      f" [{round(means_left, 4)}, {round(means_right, 4)}]")
power, ratio: 0.494, [0.4631, 0.525]
power, means: 0.328, [0.2996, 0.3577]
  • In the ratio metric we compare \(p^T\ vs.\ p^C\) (since \(\dfrac{O \cdot p}{O} = p\)).
  • In the t-test, we compare \(M^T\ vs.\ M^C\), or \({O^T \cdot p^T}\ vs.\ {O^C \cdot p^C}\), which is a noisier value due to the random variable O.

The danger of using ratio metrics

The main problem with ratio metrics is that you add a denominator to your metric, which can also change based on your changes to the website.

\(H_1: \mathbb{E} \dfrac{\sum M^T}{\sum O^T} - \mathbb{E} \dfrac{\sum M^C}{\sum O^C} > 0\) will be inconsistent with \(H_1: \mathbb{E} M^T - \mathbb{E} M^C > 0\).

Therefore, it is helpful to measure the change in the ratio metric and check the denominator using a t-test!

Therefore, your plan for working with ratio metrics is as follows:

  • If you are sure you have not affected the denominator, check the change in the ratio metric.
  • If there is a chance that you may have affected the denominator, check both the ratio metric and the denominator.

Linearization

Scaling Task

Let’s imagine you have joined a new company where AB testing is poorly organized: everyone does it however they want, making many mistakes in the process.

You decide to create a unified system for AB testing with the following features:

  • It standardizes all AB tests in the company. This reduces the number of incorrectly created AB tests. If all analysts conducted AB tests, collected data, and applied criteria, any error in the code would lead to disastrous results.
  • It significantly reduces the time required to create and analyze AB tests, which is also very important for large companies.
  • It highlights which other experiments are running in the company, which helps to avoid conducting two conflicting tests.

In this case, bootstrapping is not the best solution, as it is slow and requires a lot of memory.

Part 1. Taylor series

Let’s recall what a Taylor series is and how it can be used to write any function:

\(f(x) = \sum_{k=0}^{n}\dfrac{f^{(k)}(x_0)}{k!}(x - x_0)^k + o((x - x_0)^{n}), x \rightarrow x_0\).

If we expand the function only up to the first derivative, then:

\(f(x) = f(x_0) + f'(x_0)(x-x_0) + o((x - x_0)) \approx f(x_0) + f'(x_0)(x-x_0), x \rightarrow x_0\)

And if you have a function of two variables, then:

\(f(x, y) \approx f(\theta) + f'_x(\theta)(x-x_0) + f'_y(\theta)(y-y_0), (x, y) \rightarrow \theta, \theta := (x_0, y_0)\).

Now, let \(f(x, y) = \dfrac{x}{y}\). Then

\[\begin{align} \dfrac{x}{y} &\approx \dfrac{x_0}{y_0} + \left(\dfrac{1}{y_0}\right)(x - x_0) + \left(-\dfrac{x_0}{y^2_0}\right)(y-y_0) \\ &= \dfrac{x_0}{y_0} + \dfrac{1}{y_0}\left(x - x_0 - \dfrac{x_0}{y_0}y + x_0\dfrac{y_0}{y_0}\right) \\ &= \dfrac{x_0}{y_0} + \dfrac{1}{y_0}\left(x - \dfrac{x_0}{y_0}y \right) \end{align} \]

3Blue1Brown: Taylor series

Part 2. Decomposition

Now let’s recall our ratio metric of interest: it is \(\dfrac{\sum_i^n {X_i}}{\sum_i^n {Y_i}}\), where all values for all users of the site are summed.

Let’s move from the sum to the average: \(\dfrac{\sum_i^n {X_i}}{\sum_i^n {Y_i}} = \dfrac{\overline{X}}{\overline{Y}}\).

What interesting fact do we know about the average? According to the Law of Large Numbers, we know that:

  • \(\overline{X} \stackrel{p}{\rightarrow} \mathbb{E} X\),
  • \(\overline{Y} \stackrel{p}{\rightarrow} \mathbb{E} Y\),
  • \((\overline{X}, \overline{Y}) \stackrel{p}{\rightarrow} (\mathbb{E} X, \mathbb{E} Y)\)

Let’s then expand \(\dfrac{\overline{X}}{\overline{Y}}\) using Taylor’s formula at the point \((\mathbb{E} X, \mathbb{E} Y)\) with respect to the two variables \(\overline{X}, \overline{Y}\).

\[ \dfrac{\overline{X}}{\overline{Y}} \approx \dfrac{\mathbb{E} X}{\mathbb{E} Y} + \dfrac{1}{\mathbb{E} Y}\left(\overline{X} - \dfrac{\mathbb{E} X}{\mathbb{E} Y}\overline{Y} \right) \]

Part 3. Divide the result by \(N\) users

\[\begin{align} \dfrac{\overline{X}}{\overline{Y}} &\approx \dfrac{\mathbb{E} X}{\mathbb{E} Y} + \dfrac{1}{\mathbb{E} Y}\left(\overline{X} - \dfrac{\mathbb{E} X}{\mathbb{E} Y}\overline{Y} \right) \\ &=\dfrac{\mathbb{E} X}{\mathbb{E} Y} + \dfrac{1}{\mathbb{E} Y} \cdot \dfrac{1}{N}\sum_{i}^N \left(X_i - \dfrac{\mathbb{E} X}{\mathbb{E} Y} Y_i \right) \\ &= \dfrac{1}{N}\sum_{i}^N \left(\dfrac{\mathbb{E} X}{\mathbb{E} Y} + \dfrac{1}{\mathbb{E} Y}\left(X_i - \dfrac{\mathbb{E} X}{\mathbb{E} Y} Y_i \right) \right) \end{align} \]

Let us denote by \(Z'_i := \dfrac{\mathbb{E} X}{\mathbb{E} Y} + \dfrac{1}{\mathbb{E} Y}\left(X_i - \dfrac{\mathbb{E} X}{\mathbb{E} Y} Y_i \right)\).

Then

\[\begin{align} &\dfrac{\overline{X}}{\overline{Y}} \approx \overline Z',\\ &\mathbb{E} \dfrac{\overline{X}}{\overline{Y}} \approx \mathbb{E} \overline Z' \end{align} \]

All \(Z'_i\) are independent and identically distributed (i.i.d.) random variables, so we can use the t-test to check the hypothesis about the average value of \(Z'\). But we don’t knnow the value of \(\mathbb{E} X\) and \(\mathbb{E} Y\).

Part 4. Substitute the values

\[ Z_i = \dfrac{\overline X}{\overline Y} + \dfrac{1}{\overline Y}\left(X_i - \dfrac{\overline X}{\overline Y} Y_i \right) \]

Then we can write:

\[ (\overline{X}, \overline{Y}) \stackrel{p}{\rightarrow} (\mathbb{E} X, \mathbb{E} Y) \]

and

\[ \begin{align} Z_i \stackrel{p}{\rightarrow} \dfrac{\mathbb{E} X}{\mathbb{E} Y} + \dfrac{1}{\mathbb{E} Y}\left(X_i - \dfrac{\mathbb{E} X}{\mathbb{E} Y} Y_i \right) = Z'_i \end{align} \]

For large sample sizes, \(\mathbb{E} Z \approx \mathbb{E} Z'\). This means that \(\mathbb{E} Z \approx \mathbb{E} Z' \approx \mathbb{E} \dfrac{\overline{X}}{\overline{Y}}\).

By applying the t-test to sample \(Z\), we can compare \(\dfrac{\overline{X}}{\overline{Y}}\)

Linearization vs bootstrap: FPR

Code
def linearisation(numerator, denominator):
    E_num = numpy.mean(numerator)
    E_den = numpy.mean(denominator)
    return E_num / E_den + 1 / E_den * (numerator - E_num / E_den * denominator)

numpy.random.seed(8)

bad_cnt_linearisation = 0
bad_cnt_bootstrap = 0

for _ in range(mc_size):
    test_sample = generate_group_sample_equal_cr(group_size)
    control_sample = generate_group_sample_equal_cr(group_size)
    test_Z = linearisation(test_sample['O_array'], test_sample['message_array'])
    control_Z = linearisation(control_sample['O_array'], control_sample['message_array'])

    # Запускаю критерий и строю доверительный интервал
    left_bound, right_bound = ratio_bootstrap(
        test_sample['O_array'],
        control_sample['O_array'],
        test_sample['message_array'],
        control_sample['message_array']
    )
    pvalue_linearise = ttest_ind(test_Z, control_Z, equal_var=False, alternative='two-sided').pvalue


    bad_cnt_linearisation += (pvalue_linearise < 0.05)
    bad_cnt_bootstrap += ((left_bound > 0) | (right_bound < 0))


bootstrap_fpr = round(bad_cnt_bootstrap / mc_size, 4)
bootstrap_left, bootstrap_right = proportion_confint(count = bad_cnt_bootstrap,
                                               nobs = mc_size, alpha=0.05, method='wilson')
print(f"FPR, bootstrap: {round(bootstrap_fpr, 4)},"\
      f" [{round(bootstrap_left, 4)}, {round(bootstrap_right, 4)}]")

linearise_fpr = round(bad_cnt_linearisation / mc_size, 4)
linearise_left, linearise_right = proportion_confint(count = bad_cnt_linearisation,
                                           nobs = mc_size, alpha=0.05, method='wilson')
print(f"FPR, linearisation: {round(linearise_fpr, 4)},"\
      f" [{round(linearise_left, 4)}, {round(linearise_right, 4)}]")
FPR, bootstrap: 0.052, [0.0399, 0.0676]
FPR, linearisation: 0.049, [0.0373, 0.0642]

So we can use the linearization method to calculate the ratio metric and apply the t-test to it.

Linearization vs bootstrap: time

Code
group_size = 10000
test_sample = generate_group_sample_equal_cr(group_size)
control_sample = generate_group_sample_equal_cr(group_size)

import time
start = time.time()
left_bound, right_bound = ratio_bootstrap(
                                test_sample['O_array'],
                                control_sample['O_array'],
                                test_sample['message_array'],
                                control_sample['message_array']
                            )
end = time.time()
print(f"Bootstrap time: {round(end - start, 2)} seconds")

start = time.time()
test_Z = linearisation(test_sample['O_array'], test_sample['message_array'])
control_Z = linearisation(control_sample['O_array'], control_sample['message_array'])

pvalue_linearise = ttest_ind(test_Z, control_Z, equal_var=False, alternative='two-sided').pvalue
end = time.time()
print(f"Linearisation time: {round(end - start, 2)} seconds")
print(f"p-value: {pvalue_linearise}")
if pvalue_linearise < 0.05:
    print("Reject H0")
else:
    print("Do not reject H0")
print(f"Confidence interval: [{left_bound}, {right_bound}]")
Bootstrap time: 0.31 seconds
Linearisation time: 0.0 seconds
p-value: 0.9368145845235889
Do not reject H0
Confidence interval: [-0.039138852630568086, 0.038235767330209953]
